Without Bath Heating
The Elmasonic EASY range includes 9 units of different sizes with tank volumes ranging from 0.8 to 28 liters. Microprocessor-controlled ultrasonic cleaning with sweep technology is state-of-the-art.
Product features:
- Efficient 37 kHz ultrasonic transducers
- Cavitation-resistant stainless steel cleaning tank
- Clear and easy-to-use control unit, sealed to prevent any liquid penetration into the electronic components
- Ultrasonic function with LED display
- Simple cleaning time selection via rotary switch
- Continuous or short-duration operating mode adjustable from 1 to 30 minutes
- Permanent sweep for optimized sound field distribution via frequency modulation
- Heating protected against dry running
- Rotary switch for temperature adjustment ranging from 30°C to 80°C in 5°C increments (for H series units)
- Heating function with LED display (for H series units)
- Removable power cable with IEC connector
- Adjustable temperature limit with warning signal in case of excess
- Automatic safety shutoff after 8 hours of continuous operation
- Automatic safety shutoff when bath temperature exceeds 90°
- "Pulse" function
Technical specifications
| Voltage (Vac) | 220-240 V | Max. filling volume (l) | 2,75 |
| Ultrasonic frequencies (kHz) | 37 | Weight (kg) | 3,3 |
| Total power consumption EASY 30 H (W) | 280 | Tank material | Stainless steel |
| Effective ultrasonic power (W) | 80 | Housing material | Stainless steel |
| Max. peak ultrasonic power ** (W) | 320 | Liquid drainage | https://arcane-direct.myshopify.com/en/password |
| Heating power (W) | 200 | Handles | Yes |
| External unit dimensions L/W/H (mm) | 264/176/219 | Sound level (LpA) (In use) | < 70 dB |
| Internal tank dimensions L/W/H (mm) | 225/124/99 | Protection class | IP 20 |
| Internal basket dimensions L/W/H (mm) | 198/106/50 |
** EASY 10 – EASY 20 H: pulse signal; EASY 30 H – EASY 300 H: Dual half-wave ultrasound. The signal shape selection has been adapted to the tank geometry. Due to the signal shape, the maximum peak value of ultrasonic power is multiplied by 4 or 8.
This unit is supplied with:
- Lid
- User manual
- 2m power cable
- Without basket
Downloadable documents
